The time factor
Whether you’re dressed for business or pleasure, you’ll gladly leave the car behind for the stylish design and clever e-bike technology of the Coboc SEVEN Vesterbro. The concentrated power of the motor, re-tuned to the input of the rider, gives this model its wow effect. Add in a full suite of safety features, app connectivity, and a comfortable seating position – and the riding pleasure is complete. This smart commuter bike escorts its rider around the daily gridlock and leaves frustrated motorists gazing wistfully at its elegant tail light disappearing up the road. Those lucky enough to live in Copenhagen’s Vesterbro neighbourhood have long practiced this freedom and embraced e-bikes.
CHARGING
No trouble – with a magnetic plug. Five blue LEDs indicate your battery gauge. If switched off, you can handle the Coboc SEVEN Vesterbro like any normal bike.
HANDLING
Rear-light, smartly integrated in the seat tube, and directly powered by the battery. Carrier for two (e.g. Ortlieb) bags.
UNIT
Fully integrated electronic drive unit and robust manufacture guarantee protection for every outdoor ride. Comfortably equipped with disc brakes, stand and mudguards.
Product line SEVEN
elegant | functional | comfortable
Always ready with our perfect commuter bikes. Useful features such as lights, rear rack and mudguards make the SEVEN bikes a versatile companion on your daily commute to work or leisure. Coupled with their elegant understatement, they comfort you on your everyday rides.
Coboc SEVEN Vesterbro
| FRAME | 7020 aluminium |
| COLOUR | black, high gloss |
| FORK | carbon track fork |
| SIZES | L: 64,5 cm, from 186 cm body height M: 60,0 cm, 173 cm up to 186 cm body height S: 55,5 cm, up to 173 cm body height |
| BATTERY | li-Ion, 36V, 352 Wh |
| CHARGING TIME | 2 hours |
| RANGE | 80 km / 50 miles |
| ELECTRIC DRIVE | 250 W / 500 W peak |
| MAX TORQUE | 40 Nm |
| MECHANICAL DRIVE | single speed chain 48-17T |
| BRAKES | Shimano disk brakes, rotor 160 mm |
| TIRES | Schwalbe Kojak 622-35 |
| PEDALS | aluminium, CNC-milled, black |
| FRONT LIGHT | TSupernova E3 e-bike mini (max. 5 W) |
| REAR LIGHT | Coboc integrated LED-light |
| RACK | integrated |
| FENDER | Curana C-lit 40 mm |
| WEIGHT | 15,6 kg |
Frame Geometry
Coboc E-Drive
- Bluetooth smartphone connection
- User interface; power button, LED-display, light control and magnetic charging connector
- Internal wiring; data bus, charging cables and power supply lights
- Coboc Corepack; state-of-the-art Li-ion technology with high energy density, 36V, 352Wh, shock-absorbing and integrated construction
- Rear hub motor; 250W rated power up to 500W peak power
- Motor cable and waterproof connector
- Coboc controller; power electronics with efficient motor control unit, central and intelligent sensor signal analysis and battery management
- Torque sensor, cadence and pedal force measurements
Smart connectivity throughout the Coboc fleet
For the coming season, Coboc has loaded up in terms of connectivity. The Coboc app for iOS and Android, which was created in collaboration with the software developer COMODULE, turns all the Coboc models into fully connected smartbikes. The bike connects to a smartphone via Bluetooth, making the phone an on-board computer. In addition to adjusting the standard settings, the Coboc app can also be used to fine-tune the responsiveness of the electric assist and the motor output. This allows cyclists to individually configure the overall ride dynamics to suit their own preferences.
The on-board computer display provides information on vehicle data like speed, distance covered, battery charge level, motor output, and much more. And it not only indicates the battery’s charge level, it also visualizes the current range on the map as a function of the surrounding topography. Under the “Activity feed” menu option, it’s possible to store the trips taken, including altitude profiles and ride data, and if desired, share it with the community. Naturally, the app has a full- featured sat-nav, and on models in the SEVEN series it can be used after dark to control the rear light that’s elegantly integrated into the seat tube.
If you’re looking for a minimalist design with superior “Made in Germany” e-bike technology, you’re on the right urban racetrack with Coboc, and you can look forward to cycling fun and well-designed comfort in their purest form.
